Quick Answer: The Plus V2 uses a 12.2″ 1920×1200 touch display bonded to a thin glass digitizer, built for its 360-degree hinge and built-in stylus. Because it’s a premium consumer convertible rather than a rugged education model, the assembly is glued rather than screwed in, so replacement runs $70–$110 in parts and takes 60–90 minutes given the careful adhesive work involved.
Why the Plus V2’s Screen Job Differs
- Unlike Samsung’s rugged education Chromebooks, the Plus V2’s display and digitizer are bonded with adhesive rather than held by screws, so removal means carefully heating and prying along the bezel edge instead of just unscrewing a frame
- The built-in stylus garage and digitizer pen support mean the touch layer includes extra sensing circuitry beyond a standard touchscreen, so a replacement panel needs to specifically support pen input, not just finger touch
- Because the hinge rotates a full 360 degrees for tablet mode, the display cable takes more flex cycles over the device’s life than on a clamshell, making cable wear — not just cracked glass — a real possibility worth checking first
Fix Steps
Step 1: Confirm it’s the panel and not the graphics output
Connect to an external display if available. If external video looks fine while the built-in screen stays broken or dark, that isolates the problem to the panel or its cable rather than the graphics chip, similar to the isolation step for Samsung Chromebook touchscreen not working issues.
Step 2: Test the stylus separately from touch
If finger touch still works but the stylus doesn’t register, the issue may be limited to the digitizer’s pen-sensing layer rather than the full assembly — worth confirming before ordering a full replacement panel.
Step 3: Confirm your exact model and generation
Samsung sold both the original Chromebook Plus and the Plus V2 with different panel specs; see how to find your Chromebook model number before ordering, since the assemblies aren’t interchangeable between generations.
Step 4: Heat and separate the bonded bezel
Use a heat gun on low setting along the bezel edge to soften the adhesive, then work a plastic pry tool around the perimeter gradually rather than forcing one section, to avoid cracking an otherwise-good frame.
Step 5: Disconnect the display and digitizer cables
With the bezel free, disconnect both the video cable and the separate digitizer/pen cable at the hinge before lifting the old panel away completely.
Step 6: Install, re-bond, and test in every mode
Connect the new panel’s cables, test image quality, finger touch, and stylus input before applying fresh adhesive, then check all fold positions — laptop, tent, and tablet — once reassembled.
Repair or Replace?
At $70–$110, a screen swap on the Plus V2 is worth it if the rest of the device is healthy, given its higher-end 1920×1200 panel and stylus support aren’t cheap to replace outright with a new device. Weigh the cost against the model’s overall condition and remaining useful life.
FAQ
Can I use a generic touchscreen panel instead of the original?
No — the Plus V2’s panel includes the pen-digitizer layer that generic touch-only replacements don’t support, so stylus input will stop working with a mismatched part.
Why is this more expensive than a standard Chromebook screen?
The higher resolution panel, bonded assembly, and integrated stylus digitizer all add cost and labor time compared to a basic screwed-in touch panel on cheaper models.
Will removing the bezel damage the stylus garage?
Not if you work carefully — the stylus garage is part of the chassis, not the display assembly, so it should stay intact through a standard screen replacement.
